Uses: | ||||||||
Paste attaching for foam rubber, Plastic, leather, EVA and paper board. | ||||||||
Plaste attaching for materials for shoe-making, headgears-making, gloves, purse, clothing, and cushion of car. |
YM-2207A | |
Output | 1-60 YDS / MIN |
Air cylinder | 2 sets |
Number of Glue Groove | Single-Groove |
EPC auto cross flats unit | 5 sets |
Heat resistance press rubber round belt | ✔ |
Size of Heating Roller | 150Ø x 178cm 2 sets |
Power of electric heating tube & rated current(vapor available) |
220V 215A 1.6KWx48 = 76.8KW |
380V 125A | |
DC motor (continuously variable transmission) |
5HP Double-Step Linking-Up, Single-Up |
1HPRated Current 24.8A | |
Dimension of machine(LxWxH) | 1250cm x 270cm x 243cm |
Weight of machine(kg) | 5200kg |
YM-2207B | |
Output | 1-60 YDS / MIN |
Air cylinder | 2 sets |
Number of Glue Groove | Double-Groove |
EPC auto cross flats unit | 5 sets |
Heat resistance press rubber round belt | |
Size of Heating Roller | 150Ø x 178cm 2 sets |
Power of elevtric heating tube & rated current(vapor available) |
220V 215A 1.6KWx48 = 76.8KW |
380V 125A | |
DC motor (continuously variable trandmission) |
5HP Dounle-Step Linking-Up, Single-Up |
1HPRated Current 24.8A | |
Dimension of machine(LxWxH) | 1250cm x 270cm x 243cm |
Weight of machine(kg) | 5700kg |
